| MODEL | FREE AIR DELIVERY m³/min. |
MOTOR POWER | OUTLET | SOUND LEVEL | DIMENSIONS | WEIGHT | ||
| 7,5 Bar | 8 Bar | 10 Bar | kW/HP | inch | dB(A) | L x W x H (mm) | (Kg) | |
| HAWK 7,5 D VSD | 1,2 | 1,1 | - | 7.5/10 | 3/4" | 65 | 1000 X 700 X 830 | 230 |
| HAWK 11 D VSD | 1,8 | 1,7 | - | 11/15 | 3/4'' | 67 | 1100 X 750 X 1000 | 420 |
| HAWK 15 D VSD | 2,70 | 2,6 | 2,1 | 15/20 | 3/4'' | 67 | 1130 X 750 X 1000 | 420 |
| HAWK 22 D VSD | 3,8 | 3,6 | 3,4 | 22/30 | 1" | 70 | 1380 X 900 X 1270 | 560 |
| HAWK 37 D VSD | 6,5 | 6,2 | 5,6 | 37/50 | 1 1/4'' | 72 | 1500 X 1000 X 1320 | 795 |
| HAWK 45 D VSD | 7,4 | 7,0 | 6,2 | 45/60 | 1 1/2'' | 74 | 1500 X 1000 X 1320 | 825 |
| HAWK 55 D VSD | 10,8 | 10,2 | 9,0 | 55/75 | 2'' | 76 | 1900 X 1250 X 1600 | 1,315 |
| HAWK 75 D VSD | 13,5 | 12,6 | 11,2 | 75/100 | 2'' | 76 | 2000 X 1250 X 1670 | 1,345 |
| HAWK 90 D VSD | 16,5 | 15,0 | 13,8 | 90/125 | 2'' | 78 | 2000 X 1250 X 1670 | 1,570 |
| HAWK 110 D VSD | 21,0 | 19,8 | 17,4 | 110/150 | 2'' | 78 | 2500 X 1470 X 1840 | 2,150 |
| HAWK 132 D VSD | 24,1 | 23,5 | 20,8 | 132/180 | 2'' | 78 | 2500 X 1470 X 1840 | 2,200 |
| HAWK 160 D VSD | 28,7 | 27,6 | 23,5 | 160/200 | 3" | 81 | 3000 X 1700 X 1840 | 2,490 |
| HAWK 185 D VSD | 32,0 | 30,5 | 27,5 | 185/250 | 3" | 81 | 3000 X 1700 X 1840 | 2,720 |
| HAWK 200 D VSD | 34,2 | 33,3 | 33,0 | 200/270 | 3" | 83 | 3650 X 1980 X 2152 | 4,150 |
| HAWK 250 D VSD | 43,0 | 41,0 | 37,8 | 250/340 | 3" | 84 | 3200 X 1980 X 2150 | 4,650 |
| HAWK 315 D VSD | 51,0 | 50,2 | 41,5 | 315/422 | 3" | 86 | 3650 X 1980 X 2150 | 7,500 |
| HAWK 355 D VSD | 65,2 | 62,0 | 54,5 | 355/483 | 5" | 88 | 3650 X 1980 X 2150 | 7,550 |
| HAWK 400 D VSD | 73,5 | 72,0 | 63,1 | 400/536 | 6" | 88 | 3650 X 1980 X 2150 | 7,600 |
