| MODEL | FREE AIR DELIVERY m³/min. |
MOTOR POWER | OUTLET | SOUND LEVEL | DIMENSIONS | WEIGHT | ||
| 7,5 Bar | 10 Bar | 13 Bar | kW/HP | inch | dB(A) | L x W x H (mm) | (Kg) | |
| EAGLE SBH 7,5 | 1,2 | 0,9 | 0,8 | 7.5/10 | 3/4" | 72 | 1100 X 800 X 970 | 245 |
| EAGLE SBH 11 | 1,70 | 1,4 | 1,2 | 11/15 | 3/4'' | 72 | 1100 X 800 X 970 | 255 |
| EAGLE SBH 15 | 2,3 | 1,9 | 1,3 | 15/20 | 3/4'' | 72 | 1100 X 800 X 970 | 400 |
| EAGLE SBH 22 | 3,8 | 3,2 | 2,5 | 22/30 | 3/4'' | 74 | 1380 X 850 X 1160 | 440 |
| EAGLE SBH 37 | 5,6 | 4,8 | 4,1 | 37/50 | 1 1/4'' | 74 | 1500 X 1000 X 1330 | 765 |
| EAGLE SBH 45 | 6,5 | 5,8 | 5 | 45/60 | 1 1/2'' | 74 | 1500 X 1000 X 1330 | 900 |
| EAGLE SBH 55 | 8,9 | 7,7 | 6,5 | 55/75 | 1 1/2'' | 75 | 1900 X 1250 X 1600 | 1200 |
| EAGLE SBH 75 | 11,7 | 10,2 | 8,8 | 75/100 | 2'' | 76 | 2000 X 1250 X 1670 | 1750 |
| EAGLE SBH 90 | - | - | 10,9 | 90/125 | 2'' | 76 | 2400 X 1350 X 1770 | 2080 |
| EAGLE SBH 110 | 17,8 | - | - | 110/150 | 2'' | 77 | 2850 X 1500 X 1950 | 2880 |
| EAGLE SBH 132 | 22,4 | 18,4 | - | 132/180 | 3'' | 78 | 3400 X 1650 X 2060 | 3680 |
| EAGLE SBH 160 | - | 22,2 | - | 160/220 | 3'' | 78 | 3400 X 1650 X 2060 | 3880 |
| EAGLE SBH 250 | 44,2 | - | - | 250/340 | 3'' | 80 | 3400 X 2100 X 2500 | 6070 |
| EAGLE SBH 315 | - | 43,7 | - | 315/430 | 3'' | 81 | 3400 X 2100 X 2500 | 6700 |
